EIKO 11062 - VOL24R/PS49/FCCT/HD (New Version)
Manufacturer Code: 11062
Manufacturer Code: 11062
For larger orders, 3547 item(s) available with a 1-2 week(s) lead time.
This 2x4 volumetric retrofit kit (PowerSet selectable 49W / 39W / 34W / 29W, FieldCCT selectable 3500K / 4000K / 5000K, 120–347V, 0–10V dimming) is no longer available.
You can still purchase the updated version from us—it maintains the same volumetric design for smooth, uniform illumination, while offering selectable wattage and field-adjustable colour temperature for precise control over light output. Its 0–10V dimming ensures excellent energy savings and flexibility.
Perfect for upgrading existing fluorescent troffers, this retrofit kit modernises your lighting system, reduces maintenance costs, and delivers mercury-free, energy-efficient performance with a long service life.
Note: As LED retrofits age, brightness and colour may shift slightly. When installed next to older units—even if they were originally identical—you may notice subtle differences in tone or output. This is expected behaviour for LED lighting.
| Kelvin | Selectable 3500/4000/5000 |
|---|---|
| Volts | 120-347VAC |
| Watts | Selectable 29, 34, 39, or 49W |
| Lumens | Selectable 3700, 4400, 5000, or 6300 lumens |
| Colour Rendering Index (CRI) | 80+ |
| Average Life in Hours | 50000 |
| Temperature Range | -20 to 40C (-4 to 104F) |
| Manufacturer Description | Volumetric Retrofit 2×4 PowerSet 49/39/34/29W FieldCCeT 35/40/5000K 120-347V 0-10V Dimming |
| Manufacturer Code | 11062 |
| Dimmable | Yes |
| Certification ETL | No |
| Manufacturer Name | EIKO |
| Cct | 3500/4000/5000 |
|---|---|
| Cri | 80+ |
| Dimming | Yes |
| Dlc version | Dlc standard |
| Efficacy (lm/w) | 130 lm/w |
| Etl | No |
| Description | Volumetric retrofit 2x4 powerset 49/39/34/29w fieldccet 35/40/5000k 120-347v 0-10v dimming |
| Brand | Eiko |
| Lumens (lm) | 3,700/4,400/5,000/6,300 lm |
| Operating temp range (°f/°c) | -4f to 104f (-20c to 40c) |
| Rated life | 50,000 |
| Replacement for/equivalent | 2x 32t8, 3x 32t8 fluorescent |
| Voltage | 120-347vac |
| Wattage | 29/34/39/49w |
| Item id | Vol24r/ps49/fcct/hd |
| Item type | Fixtures |
| Order code | 11062 |
By purchasing this product, you acknowledge that UV lamps can be harmful if misused. Please follow all safety instructions.
This UV and/or Germicidal lamp emits ultraviolet radiation and is intended for controlled environments only. UV radiation can be hazardous to health if not handled properly.
By purchasing and using this product, the customer agrees and acknowledges full responsibility for:
While this product is manufactured to high standards, no guarantees are made regarding its effectiveness for any particular scientific method, simulated environment, water purification process, research outcome, industrial application, manufacturing process, or experimental result. Environmental factors, usage conditions, and application requirements vary widely, and it is the sole responsibility of the customer to determine suitability.
Any lab data, technical specifications, or performance information provided is for reference only and does not constitute a warranty or performance guarantee.
The seller disclaims all liability for injury or death, including humans, animals and plants, property damage, invalid results, performance failures, or regulatory noncompliance resulting from misuse, misapplication, inadequate testing, defective lamps, improperly manufactured or mislabelled lamps or failure to follow appropriate safety protocols.
Use at your own risk.
